Cutting and grinding wheels
Cut-off, grinding, chopsaw and rail cutting wheels, ordered by diameter, thickness and bore and quoted on the same line list as the rest of your shutdown. Synergy Services Corporation is an authorized dealer for GEETEE ABRASIVES, supplying across India. We respond to any enquiry within 24 to 48 hours.
What we supply.
GEETEE wheels are resin bonded, in brown or white aluminum oxide, or silicon carbide for non-ferrous metals and cast iron.
| Wheel | Sizes | Used for |
|---|---|---|
| Reinforced cut-off wheels | 80 to 500 mm diameter, 3 to 8 mm thick (0.8 to 10 mm on request) | Notching, sheet, pipe and bar cutting, runner and riser removal, rail cutting, stainless steel |
| Plain (non-reinforced) cut-off wheels | 250 to 500 mm diameter, 1.5 to 3.2 mm thick | Fixed-base machines with the work clamped: lab specimens, cable, collets, steel rod |
| Reinforced cut-off grinding wheels | 50 to 800 mm diameter, from 0.8 mm thick | Riser and runner removal on stationary and swing-frame cutters, dry or wet |
| Snagging wheels | – | Weld seams, cleaning castings, billet conditioning, fettling in foundries |
| Chopsaw wheels | 350 × 2.5 × 25.4 mm (14 in) | Rod, pipe, angle, channel and heavy rebar |
| Ultra-thin wheels | 107 × 1 × 16 mm | Fast general cutting on mild and stainless steel |
| Depressed center discs | 7 in and 9 in | Weld removal and blending, beveling, scale removal |
| Rail cutting wheels | 400 × 4 × 22.23 mm (16 in) | Rail sections up to 65 kg/m and up to 110 UTS |
Standard sizes.
Reinforced cut-off wheels, in millimeters. Other thicknesses from 0.8 to 10 mm are made on request.
| Diameter | Thickness | Bore |
|---|---|---|
| 80 | 3 | 6.35 |
| 100 | 3 | 22.23 |
| 180 | 3 | 22.23 |
| 230 | 3 | 22.23 |
| 250 | 3.7 | 22.23 |
| 300 | 3 | 25.04 |
| 300 | 3.8 | 22.23 |
| 350 | 3 | 25.4 |
| 350 | 6 | 22.23 |
| 400 | 3 | 25.4 |
| 400 | 4 | 25.4 |
| 400 | 8 | 76.2 |
| 500 | 3.2 | 31.76 |
By application.
| If the job is | Use |
|---|---|
| Rail track maintenance | Rail cutting wheel, for petrol or electric rail cut-off machines |
| Foundry: risers, runners and fettling | Foundry reinforced cutting and grinding wheels; snagging wheels. Silicon carbide wheels for cast iron |
| Metallurgical lab sectioning | Plain cut-off wheels, 250 to 500 mm, for wet cutting of specimens up to 70 HRC. Grade matched to the specimen |
| Cylinder liner cutting | Wheels from 350 to 500 mm, graded to the liner material and geometry |
| Control cable conduit | Wheels made to the conduit, for continuous cutting of brake, clutch and throttle cable casing |
| Fabrication and welding | Cutting wheels from 100 to 350 mm; depressed center grinding discs in 7 and 9 in |
Send the machine the wheel runs on and the material you cut or grind, and we will match the wheel.
Questions.
What do you need from me to quote a wheel?
The diameter, thickness and bore, the machine it runs on, and the material you cut or grind. A photo of the label on the wheel you use now is enough.
Which brand of wheel do you supply?
We are an authorized dealer for GEETEE ABRASIVES, which has made cutting and grinding wheels in Chennai since 1977.
Can you supply a wheel for a lab cut-off machine or a special size?
Yes. Plain and reinforced wheels can be made to a non-standard diameter, thickness or grade. Send the machine, the specimen material and the size.
Can abrasives go on the same order as other maintenance supplies?
Yes. Abrasives, coatings, gases, pump spares and welding consumables can all sit on one quotation and one purchase order.
Are these held in stock?
No. We carry sample quantities and order against your requirement.
How quickly do you respond to an enquiry?
We respond to any enquiry within 24 to 48 hours.
